U2 Fasteners

U2 FASTENERS Universal Screw is ideal for replacing those old deck screws. The features of the Universal Screw work together to drive and secure this screw in many types of materials that are used in residential construction.

FEATURES:
- Chrome 6 free & Prop 65 compliant

U-Gold coating.
- Structural & ACQ treated lumber compliant. See report ER-454.
- Tapper Point, consisting of the Cork Screw Start and Blade Cutting Thread for easy piercing and alleviating strain on the material.
- Tight Star Recess system grasps the U-Bit tightly and can be installed with one hand.
- Underneath the Universal head Burrow Pockets are dynamically engineered to help countersink into the toughest of materials.
- Below the smooth shank is the Reamer Thread, which enlarges the hole to create a passage when drawing materials together and reduces tension for the screw head.

#6, #8 screws take a T-15 U-Bit.

#9, #10, #12 screws take a T-25 U-Bit.

The U2 Construction Screw also known as CS Screw, is the next generation of construction screws that are replacing lag screws.

FEATURES:
- Chrome 6 free & Prop 65 compliant

U-Gold coating.
- Structural & ACQ treated lumber compliant. See report ER-454.
- Dome Head enhances the structural capability.
- Tapper Point which consists of the Cork Screw Start and Blade Cutting Thread for easy piercing and alleviating strain on the material.
- Tight Star Recess system grasps the U-Bit tightly and can be installed with one hand.
- Talon Grip holds the screw tight to prevent loosening and uses its nibs to dig into the material when countersunk.
- Reamer Thread enlarges the hole in the material to create a larger passage when drawing materials together and reduces tension on the screw head.

#10 and #1/4 screws take a T-25 U-Bit.

5/16" screws take a T-30 U-Bit.

3/8" screw takes a T-40 U-Bit.

The Fine Screw is designed especially for carpenters who do fine professional work. When building the most delicate of projects, contractors prefer Fine ScrewTM for its modest head size. Also available in WHITE.

FEATURES:
- Chrome 6 free & Prop 65 compliant U-Gold

coating.
- With its slim shank and bulging thread this screw can be used without damaging even the hardest wood.
- Tapper Point which consists of the Cork Screw Start and Blade Cutting Thread for easy piercing and alleviating strain on the material.
- Tight Star Recess system grasps the U-Bit tightly and can be installed with one hand.

Available in lengths of 1-1/4” to 5” in case hardened steel, WHITE and in lengths of 1-1/2” to 3” made of 316 Marine Grade Stainless Steel.

#8 screws take a T-10 U-Bit.

#9 screws take a T-15 U-Bit.

The Re-Fine Screw is the brother to the Fine ScrewTM but has the RE-FINE Thread that depresses synthetic materials for a clean finished appearance. Also available in WHITE.

FEATURES:

- Chrome 6 free & Prop 65 compliant U-Gold coating.
- With its slim shank and bulging thread this screw can be used without damaging even the hardest wood.

- Tapper Point which consists of the Cork Screw Start and Blade Cutting Thread for easy piercing and alleviating strain on the material.

- Tight Star Recess system grasps the U-Bit tightly and can be installed with one hand.
- RE-FINE Thread depresses synthetic surface materials for a clean finished appearance.

Available in lengths of 2” to 3-1/8” in case hardened steel in WHITE case hardened steel.

#8 screws take a T-10 U-Bit.

#9 screws take a T-15 U-Bit.

The Cap Screw is an ideal light duty interior and exterior screw. This screw makes all your small projects easier with the drawdown strength of the head and the clean finish.

FEATURES:

- Chrome 6 free & Prop 65 compliant U-Gold coating.
- Dome Head with rim and Cutting Ribbon underhead.
- Tapper Point which consists of the Cork Screw Start and Blade Cutting Thread for easy piercing and alleviating strain on the material.
- Tight Star Recess system grasps the U-Bit tightly and can be installed with one hand.

Available in lengths 1-1/4” to 3-1/8” and in lengths of 1-1/4" to 1-1/2” available in 305 Grade Stainless Steel.

#8 screws take a T-15 U-Bit.

#10 screws take a T-25 U-Bit.

The Steel Siding Screw is an ideal metal roofing, siding, garage door seal, trim and flashing screw,with a low profile white powder coated head and EPDM washer.

FEATURES:

Dome Head, Powder coated WHITE with rim and black EPDM rubber washer. Tapper Point which consists of the Cork Screw Start and Blade Cutting Thread for easy piercing and alleviating strain on the material.

Tight Star Recess system grasps the U-Bit tightly.

Available in length of 10 x 1-1/2” in case hardened carbon steel.

The Vinyl Extrusion Screw is an adjustable screw ideal for vinyl window retro-fits over old aluminum window frames. It has a small low profile white powder coated head and tek drill point.

FEATURES:

- Dome Head, Powder coated WHITE with rim.
- Tek Point and Blade Cutting Thread for easy piercing and alleviating strain on the material.

- Tight Star Recess system grasps the U-Bit tightly.

Available in length of 10 x 3-1/8” in case hardened carbon steel.

These #10 screws take a standard T-25 Bit.

The adjustable screw replaces shimming and can make door hanging a one person job. The TopStarTM is designed to replace shims when levelling doors, windows and cabinets. Use the Crown Bit to install and only the bit to re-adjust to level.

Available in lengths 2-1/2”, 3-1/8” and 4”

1. Predrill window frame/ door jamb (only) with 5/16" drill
2. Engage crown bit into TopStarTM screw head and drive flush to surface of frame or jamb.
3. For adjustments remove crown from bit. The adjustable screw replaces shimming and can make door hanging a one person job. Easy 4 Step Wood to Wood Installation
4. Engage bit into center hole of TopStarTM screw head and adjust to your requirements.

TopStar screws use the Topstar Crown Bits.

The U-BitsTM are specifically designed to fit snug & firm on the Tight Star Recess of the U2 FASTENERS screw assortment. However, U2 FASTENERS also fit the traditional star drive. U-BitsTM are impact driver ready and are made of hardened steel to prevent wear and tear.

Sizes range of 1” to 3” in T-10, T15, T-20, T-25, T-30 and T-40. Packaged in cards of two bits per card or in packs of 25pcs.
